Introducing The PowerRad Board!

The POWERAD BOARD is a heated and insulated panel which can replace standard size plasterboard where a heating solution is required in a building. POWERAD BOARD incorporates a third party proprietary heating film to provide a simple and efficient radiant heating system for residential and commercial ceiling applications. This product provides a comfortable and low-cost sustainable heating solution with built-in over-heat protection for increased safety.

PoweRad Systems Can Be Installed Practically Anywhere!

RESIDENTIAL HOMES

OFFICES

SCHOOLS

CARE HOMES

STUDENT ACCOMMODATION

Specifications

12.5mm & 15mm Thick Version Available

We've made our PowerRad Board the exact same thickness as UK standard 12.5mm & 15mm plasterboard for seamless integration into any ceiling.

Paper Coating

An outside paper coating gives the exact appearance and texture of plasterboard, again this helps blend the material into most ceiling installs, it also has the same adhesion properties as plasterboard and can be skim plastered or painted.

0.5mm Embeded Steel Board

This covers the entire surface of the board and makes up the earthing fire and shock safety mechanism, this ensures protection from electric shock. Should a screw penetrate the board it will trip the electrical circuit, simply remove the screw and fill the hole, the board works safely and exactly as it did before.

Infrared Heating Element

3rd party proprietary heating element, this is what gives our PowerRad Board it's outstanding performance. The composition of this is carbon fibre organic polymers which are environmentally friendly in both creation and disposal.

Insulation

The insulation layer is for retention of heat, it's configuration helps to give our PoweRad Board it's high performance rating.

Composite Skin

Combined with the steel layer, this is what gives our product it's amazing strength and durability. The composite skin is also a very good conductor of heat, forcing residual heat downward into the desired area.

Real World Comparison

Based on 60m2 system over 15 Years

So why chose a PoweRad Board system over, lets say the recently popular Air Source Heat Pump system? We thought you'd ask, so we've created this side by side comparison to show you the astonishing savings a PoweRad Board system can offer based on the average square metreage property we come across in industry.

And it's not just superior to an ASHP system, check out the Cost Comparison section for details on performance compared with the other market offerings available.

ASHP Full System

Fixed Costs

  • Purchase Price

    £5,932.00
    Mitsubishi 5Kw Ecodan Air Source Heat Pump, 5kw model chosen for similar performance. Price at the time this article was written.
  • Installation Cost

    £4,750.00
    Industry standard installation and integration cost at the time this article was written.
  • Yearly Services Total

    £3,000.00
    Servicing at a cost of £200 per visit on a yearly basis.

Total Cost = £13,682.00

Other things to consider are:

  • The price above doubles if you base the system on a 30-year basis, due to the average lifetime of an ASHP system being only 15 years.
  • The current running cost of an ASHP system is >5% that of an equivelent PoweRad system.
  • Gas prices will increase as the penalties for non-renewable fuels increases. Currently, there aren't any, yet Gas prices still increase year-on-year by an average of 5%.
  • ASHP systems are dependent on boiler/central heating infrastructure, there is an associated cost for maintaining these types of systems or in the case of new installs there is a significant cost for the install of a boiler/centeral heating system.
  • Disruption is very likely and quite intense.

PoweRad Board Full System

Fixed Costs

  • Purchase Price

    £4,600.00
    Based on the average number of boards required for equivalent system.

  • Installation Cost

    £3,750.00
    Industry standard installation and integration cost at the time this article was written.
  • Yearly Services Total

    £0.00
    PoweRad Boards are enclosed technology and require no servicing.

Total Cost = £8,350.00

Other things to consider are:

  • The average lifespan of a PoweRad system is 30 years, double that of an ASHP system.
  • The current running cost of a PoweRad system is <5% that of an equivalent ASHP system.
  • PoweRad Systems are 100% power by electricity and thus can be powered from renewable sources
  • Electricity prices are likely to decrease as incentives for renewable energy become available and cost to produce electricity decreases as more renewable plants are built.
  • PoweRad systems are stand-alone systems, there are no additional requirements other than a supply of electricity.
  • Disruption is minor.

Cost Comparison

Purchase Cost (£k)

  • Boiler & Radiators (4.25)
  • Boiler & UFH (6.00)
  • Air Source & UFH (9.00)
  • PoweRad Board (4.75)

Service & Replacement Cost (£k)

  • Boiler & Radiators (2.70)
  • Boiler & UFH (2.70)
  • Air Source & UFH (6.75)
  • PoweRad Board (0.00)

Installation Time (Days)

  • Boiler & Radiators (7.00)
  • Boiler & UFH (7.00)
  • Air Source & UFH (10.00)
  • PoweRad Board (3.00)

Installed Power (KW)

  • Boiler & Radiators (12.00)
  • Boiler & UFH (12.00)
  • Air Source & UFH (6.00)
  • PoweRad Board (4.00)

Lifetime Expectancy (Years)

  • Boiler & Radiators (15.00)
  • Boiler & UFH (15.00)
  • Air Source & UFH (15.00)
  • PoweRad Board (30.00)

Consumption Cost (£k)

  • Boiler & Radiators (15.15)
  • Boiler & UFH (15.15)
  • Air Source & UFH (14.18)
  • PoweRad Board (13.64)

Total Ownership Cost (£k)

  • Boiler & Radiators (22.10)
  • Boiler & UFH (23.85)
  • Air Source & UFH (29.93)
  • PoweRad Board (18.39)

PoweRad Board In The UK

0

Customers

0

PoweRad Boards Installed

0

Kilowatts Saved

Unlimited

Potential

Bill Of Materials Calculator

Room Size (m)
If you would like a price on all components for this size system please enter your email below and click Request Price.
